From the heart of Manama’s industrial landscape, Rizwan Flanges stands as a dedicated manufacturer and supplier, committed to providing robust solutions for demanding piping systems. Our expertise shines in the production of EN 1092-1 Type 13 Flanges, where precision engineering meets the highest international standards. We understand that reliability is paramount, which is why our focus is on delivering high-integrity components that ensure secure, leak-proof connections for our clients across Bahrain and beyond, building trust with every product we supply.
When it comes to composition, the Type 13 Flange is typically crafted from high-quality carbon or stainless steel, chosen for its excellent mechanical strength and durability. These materials are carefully processed to meet the rigorous specifications of the EN 1092-1 standard, ensuring the final product can withstand significant pressure and temperature fluctuations. This results in a flange with remarkable toughness and resilience, perfectly suited for creating a strong, permanent connection between pipes or equipment in challenging environments.
Rizwan Flanges, a leading supplier in Manama, Bahrain, offers an extensive selection of EN 1092-1 Type 13 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Pressure | PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160 |
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| DN | GAS | Diameters | Thickness | Total | Diameter | Radius | Net | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Outside | bolt | bolt | Bolts | thickness | of the | weight | |||||
| circle | holes | Nr | Type | neck | |||||||
| D | K | L | C2 | H1 | d1 | R1 | Kg | ||||
| 15 | 1/2 | 80 | 55 | 11 | 4 | M10 | 12 | 20 | 30 | 4 | 0,43 |
| 20 | 3/4 | 90 | 65 | 11 | 4 | M10 | 14 | 24 | 40 | 4 | 0,66 |
| 25 | 1 | 100 | 75 | 11 | 4 | M10 | 14 | 24 | 50 | 4 | 0,82 |
| 32 | 1.1/4 | 120 | 90 | 14 | 4 | M12 | 14 | 26 | 60 | 6 | 1,17 |
| 40 | 1.1/2 | 130 | 100 | 14 | 4 | M12 | 14 | 26 | 70 | 6 | 1,4 |
| 50 | 2 | 140 | 110 | 14 | 4 | M12 | 14 | 28 | 80 | 6 | 1,59 |
| 65 | 2.1/2 | 160 | 130 | 14 | 4 | M12 | 14 | 32 | 100 | 6 | 2,17 |
| 80 | 3 | 190 | 150 | 18 | 4 | M16 | 16 | 34 | 110 | 8 | 3,2 |
| 100 | 4 | 210 | 170 | 18 | 4 | M16 | 16 | 40 | 130 | 8 | 3,59 |
| 125 | 5 | 240 | 200 | 18 | 8 | M16 | 18 | 44 | 160 | 8 | 4,94 |
| 150 | 6 | 265 | 225 | 18 | 8 | M16 | 18 | 44 | 185 | 10 | 5,83 |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | k | D | b | h1 | d3 | d4 | f | d2 | Thread | Bolt holes | KG | |
| 15 | 21,3 | R 1/2″ | 65 | 95 | 16 | 22 | 35,0 | 45,0 | 2,0 | 14 | M12 | 4 | 0,722 |
| 20 | 26,9 | R 3/4″ | 75 | 105 | 18 | 26 | 45,0 | 58,0 | 2,0 | 14 | M12 | 4 | 1,040 |
| 25 | 33,7 | R 1″ | 85 | 115 | 18 | 28 | 52,0 | 68,0 | 2,0 | 14 | M12 | 4 | 1,250 |
| 32 | 42,4 | R 1-1/4″ | 100 | 140 | 18 | 30 | 60,0 | 78,0 | 2,0 | 18 | M16 | 4 | 1,810 |
| 40 | 48,3 | R 1-1/2″ | 110 | 150 | 18 | 32 | 70,0 | 88,0 | 3,0 | 18 | M16 | 4 | 2,060 |
| 50 | 60,3 | R 2″ | 125 | 165 | 18 | 28 | 84,0 | 102,0 | 3,0 | 18 | M16 | 4 | 2,390 |
| 65 | 76,1 | R 2-1/2″ | 145 | 185 | 18 | 32 | 104,0 | 122,0 | 3,0 | 18 | M16 | 4 | 2,970 |
| 80 | 88,9 | R 3″ | 160 | 200 | 20 | 34 | 118,0 | 138,0 | 3,0 | 18 | M16 | 8 | 3,780 |
| 100 | 114,3 | R 4″ | 180 | 220 | 20 | 40 | 140,0 | 158,0 | 3,0 | 18 | M16 | 8 | 4,380 |
| 125 | 139,7 | R 5″ | 210 | 250 | 22 | 44 | 168,0 | 188,0 | 3,0 | 18 | M16 | 8 | 6,070 |
| 150 | 168,3 | R 6″ | 240 | 285 | 22 | 44 | 195,0 | 212,0 | 3,0 | 22 | M20 | 8 | 7,240 |
EN 1092-1 Type 13 flanges are widely used in piping systems across various industries, particularly for low to medium-pressure applications where welding isn’t feasible or desirable. Their threaded design makes them ideal for installations that require frequent assembly and disassembly, such as in maintenance-intensive systems, temporary pipelines, and testing setups. Commonly employed in industries like water treatment, oil and gas, chemical processing, and HVAC, these flanges allow for efficient, secure connections in piping systems, providing both flexibility and reliability for routine access and inspection.
Yes, we offer custom sizes for EN 1092-1 Type 13 Flanges
to meet specific project needs. Our team at Rizwan Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@rizwanflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
