Strategically located in the industrial heart of Manama, Rizwan Flanges stands as a trusted name for high-quality pipeline components. We specialize in the supply and manufacture of robust DIN 2527 PN10 Blind Flanges, engineered to meet the most demanding standards. Ideal for capping or isolating sections of a piping system, these flanges are a cornerstone of safe and efficient operations across various sectors. Our commitment in Bahrain is to provide durable, reliable solutions that ensure the integrity and longevity of your critical infrastructure projects, backed by expert local support.
Crafted to the precise specifications of the DIN 2527 standard, these PN10 rated blind flanges are typically manufactured from durable carbon or stainless steel. The composition ensures excellent strength and resistance to corrosion, providing a long service life even under continuous pressure. Their mechanical properties are rigorously tested to guarantee they can reliably handle a nominal pressure of 10 bar, forming a secure and leak-proof seal. This focus on material integrity and performance makes them a fundamentally sound and dependable choice for any piping system.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| D | b | k | Number | Thread | d2 | Shape B | |
| Kg | |||||||
| 15 | 95 | 14 | 65 | 4 | M 12 | 14 | 0,72 |
| 20 | 105 | 16 | 75 | 1,01 | |||
| 25 | 115 | 16 | 85 | 1,23 | |||
| 32 | 140 | 16 | 100 | M 16 | 18 | 1,8 | |
| 40 | 150 | 16 | 110 | 2,09 | |||
| 50 | 165 | 18 | 125 | 2,88 | |||
| 65 | 185 | 18 | 145 | 3,66 | |||
| 80 | 200 | 20 | 160 | 4,77 | |||
| 100 | 220 | 20 | 180 | 8 | 5,65 | ||
| 125 | 250 | 22 | 210 | 8,42 | |||
| 150 | 285 | 22 | 240 | M 20 | 22 | 10,4 | |
| 200 | 340 | 24 | 295 | 16,5 | |||
| 250 | 395 | 26 | 350 | 12 | 24 | ||
| 300 | 445 | 26 | 400 | 30,9 | |||
| 350 | 505 | 26 | 460 | 16 | 40,6 | ||
| 400 | 565 | 26 | 515 | M 24 | 26 | 49,4 | |
| 500 | 670 | 28 | 620 | 20 | 75 | ||
Rizwan Flanges, a leading supplier in Manama, Bahrain, offers an extensive selection of DIN 2527 PN10 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2527 PN10 Blind Flanges are used to securely close off pipeline ends, valves, and equipment openings in low to moderate-pressure systems. They are commonly employed in industries such as oil and gas, petrochemical, water treatment, and chemical processing, where they serve to isolate sections of piping for maintenance, inspection, or repair without causing system-wide disruptions. These flanges ensure leak-proof sealing, which helps maintain system integrity and prevent contamination. Their durability and ease of use make them essential components in managing pipeline and equipment access points.
Yes, we offer custom sizes for DIN 2527 PN10 Blind Flanges to meet specific project needs. Our team at Rizwan Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@rizwanflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2527 PN10 BLRF Flange Stockist in Bahrain | Raised Faced DIN 2527 PN10 Slip-On flanges Dealer in Bahrain |
| Nickel Alloy DIN 2527 PN10 Blind Flange | Mild Steel DIN 2527 PN10 Blind Flange |
| Stainless Steel DIN 2527 PN10 Blind Flange | ASTM B564 Raised Faced DIN 2527 PN10 Blind Flanges |
| DIN 2527 PN10 Blind FF Flange Supplier | Suppliers of DIN 2527 PN10 Blind Flange |
| DIN 2527 PN10 Blind Flange Dimensions | Raised Face DIN 2527 PN10 Blind Flange Manufacturer |
| 18 inch DIN 2527 PN10 Carbon Steel Blind Flange | DIN 2527 PN10 Blind Flange Dimensions in mm |
| Alloy Steel DIN 2527 PN10 Blind Flanges | Copper Nickel DIN 2527 PN10 Blind Flanges at Best Price |
| 8 Inch DIN 2527 PN10 Blind Pipe Flanges | DIN 2527 PN10 Blind Flanges Stockist |
| DIN 2527 PN10 BLRF Flange Exporter | DIN 2527 PN10 Blind Flange Pressure Ratings |
| Raised Face DIN 2527 PN10 Blind Plate Flanges | Titanium DIN 2527 PN10 Blind Flanges |
| DIN 2527 PN10 Large Diameter Blind Flange | 30 Inch DIN 2527 PN10 Blind Pipe Flange Dimensions |
| 30 inch DIN 2527 PN10 Blind Flange Dealer | Raised Face DIN 2527 PN10 Blind Flanges Manufacturer |
| 4 inch Stainless Steel DIN 2527 PN10 Blind Flange | DIN 2527 PN10 Blind RF Flanges Stockholder |
| DIN 2527 PN10 Blind Flanges Supplier in Manama | MS DIN 2527 PN10 Blind Flange |
| ASME SA105N Raised Faced DIN 2527 PN10 Blind Flanges | 18 inch Carbon Steel DIN 2527 PN10 Blind Flange |
| DIN 2527 PN10 Blind Flange Manufacturer | Flat Face DIN 2527 PN10 Blind Flange Manufacturer |
| DIN 2527 PN10 BLRF Flanges Distributor in Sitrah | Flat Face DIN 2527 PN10 Blind Flanges Exporter |
| German Standard DIN 2527 PN10 Blind Flanges | DIN 2527 PN10 Blind Flange Supplier in Bahrain |
| Carbon Steel DIN 2527 PN10 Blind Flange | DIN 2527 PN10 Blind RF Flange Supplier |
| Carbon Steel Raised Face DIN 2527 PN10 Blind Flange Stockist | Duplex Steel DIN 2527 PN10 BLRF Flanges Supplier in Manama |
| DIN 2527 PN10 Blind Pipe Flanges Supplier in Riffa | Duplex Steel DIN 2527 PN10 Blind Flanges |
| DIN 2527 PN10 BLRF Flanges Supplier in A’ali | Alloy Steel DIN 2527 PN10 Blind Flanges Manufacturer in Bahrain |
| DIN 2527 PN10 Blind Pipe Flanges Wholesaler | DIN 2527 PN10 BLRF Flanges Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
